Data sheet?
| Output power | 50W |
|---|
| Input Voltage | 100-240VAC~ 50/60Hz |
|---|
| Permissible voltage | 85-264VAC~50/60Hz |
|---|
| Output_Voltage | 24VDC  |
|---|
| Output_Current | 2 .1A |
|---|
| Mounting type | Using Bolts |
|---|
| Protection | Over-Current,Inrush Current,Output Short-Circuit |
|---|
| Approval |  |
|---|
| Input_Frequency | 50/60Hz |
|---|
| Input_Efficiency | Min. 80% |
|---|
| Input_Current consumption | Max. 1.1A |
|---|
| Output type_Voltage adjustment range | ?5% |
|---|
| Output type_Input fluctuation ratio | Max. ?0.5% |
|---|
| Output type_Load fluctuation ratio | Max. ?1% |
|---|
| Environment_Ambient temperature | -10 to 50??/td> |
|---|
| Environment_Ambient humidity | 25 to 85%RH, storage: 25 to 90%RH |
|---|
| Weight | Approx. 350g |
|---|
??00% load for rated input voltage (100VAC).
??ated input voltage
??PA-030/050 Series: 100-240VAC (85-264VAC)
??PA-075/100 Series: 100-120/200-240 (85-132/170-264VAC)
under 100% of load.
SPA-100-05 is under 100% of load for [100-120/200-240VAC (100-132/190-264VAC)].
??ated input voltage (100VAC).
??djusting voltage by the output voltage adjuster (V.ADJ), it is changed the within voltage adjustment range.
??nvironment resistance is rated at no freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
