Data sheet?

Sensing type	Retroreflective type
Sensing distance	1m(MS-2)
Sensing target	Opaque material of min. ?60mm
Light source	Infrared LED(940nm)
Response time	Max. 3ms
Power supply	12-24VDC ?10%(ripple P-P: max. 10%)
Current consumption	Max. 40mA
Sensitivity adjustment	Fixed
Operation mode	Dark ON
Control output	NPN open collector
Connection type	Cable type(?4, 2m)
Environment_Ambient illumination	Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature	-10 to 60?? storage: -25 to 70??/td>
Approval
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Material	Case: Acrylonitrile butadiene styrene, Sensing part: Acryl, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum
Accessories_Individual	Reflector(MS-2)
Accessories_Common	Fixing bracket, Bolts, Nuts
Weight	Approx. 105g

??t is mounting distance between sensor and reflector MS-2 and it is the same when MS-5 is used. It is detectable under 0.1m.
When using reflective tapes, the reflectivity will vary by the size of the tape. Please refer to the ??? Reflectivity By Reflective Tape Model??br>table before using the tapes.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
