Data sheet?

Wire type and power	DC 4-wire type 12-48VDC
Sensing side size	Frame size 80mm
Sensing distance	50mm
Standard sensing target	150?150?1mm(iron)
Response frequency	30Hz
Current specification	Current consumption: Max. 20mA
Control output	PNP Normally Open+Normally Closed
Sensing type	Upper sensing type
Protection structure	IP67
Approval
Environment_Ambient temperature	-25 to 70?? storage: -30 to 80??/td>
Environment_Ambient humidity	35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)	Max. 15% of sensing distance
Weight	Approx. 470g

??he response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
??he weight includes packaging. The weight in parenthesis is for unit only.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
