| Display method | 4-digit 7-segment LED |
|---|---|
| Character height | 14.2mm |
| Max. display Range | -1999 to 9999 |
| Measurement | DC voltage |
| Input specification | 0-500V, 0-100V, 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Power supply | 12-24VDC @(=) |
| Output_Main Output(Comparative Value) | NPN open collector (HI, GO, LO) |
| Output_Sub Output(Display Value) | RS485 communication |
| Approval | @(CE) @(CULUS) |
| Display accuracy | ??23?????- F.S. ?0.1% rdg ?2-digitF.S. +0.3% rdg ?3-digit max. only for 5A terminal.??-10??to 50??- F.S. ?0.5% rdg ?3-digit |
| Max. allowable input | 110% F.S. for each measured input range |
| A/D conversion method | ?? (Sigma Delta) ADC |
| Sampling cycle | 50ms |
| Hold function | Includes (external hold function) |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: 1kV) |
| Weight | Approx. 326g (approx. 211g) |
Tags: Meter, DC Volts, LED, W96xH48mm, 4-Digit, 0-500V Input, 3 NPN Outputs + RS485 Output, 12-24VDC
