| Driver_Applied Motor | Frame size 60mm 2-phase closed loop stepper motor |
|---|---|
| Driver_Resolution | 500, 1000, 1600, 2000, 3200, 3600, 5000, 6400, 7200, 10000(SW2) |
| Driver_Power supply | 200-240VAC~ |
| Driver_Max. Run Current | 2A/Phase |
| Driver_Max. Power consumption | 160W |
| Driver_Protection structure | IP20(IEC standard) |
| Driver_Approval | @(CE) |
| Driver_Environment_Ambient temperature | 0 to 50?? storage: -10 to 60??/td> |
| Driver_Environment_Ambient humidity | 35 to 85%RH, storage: 10 to 90%RH |
| Driver_Weight | Approx. 1,080g(approx. 800g) |
Tags: Controller-Intergrated Type, 2-Phase Closed-Loop Stepper Motor Driver, RS485, For AiA-M-60MA Motor, 200-240VAC
