| Size | DIN W72?H72mm |
|---|---|
| Display method | 4-digit 7-segment LED |
| Control method | ON/OFF control, P, PI, PD, PID control |
| Input specification | Thermocouple: K(CA), J(IC), L(IC)RTD: DPt100?, Cu50? |
| Sampling cycle | 100ms |
| Control output | Relay (250VAC~ 3A) or SSR drive (12VDC @(=)) [ON/OFF, phase, cycle] |
| Option output | Alarm 1 |
| Power supply | 100-240VAC~ 50/60Hz |
| Approval | @(CE) @(CULUS) |
| Display accuracy_RTD | ??t room temperature(23?C ? 5?C):(PV ? 0.5% or ?1?C, select the higher one) ? 1-digit??ut of room temperature range:(PV? 0.5% or ?2?C, select the higher one)? 1-digit |
| Display accuracy_Thermocouple | ??t room temperature(23?C ? 5?C):(PV ? 0.5% or ?1?C, select the higher one) ? 1-digit??ut of room temperature range:(PV? 0.5% or ?2?C, select the higher one)? 1-digit |
| Hysteresis(adjustable sensitivity) | 1 to 100????0.1 to 50.0???? variable |
| Proportional band | 0.1 to 999.9????/td> |
| Integral time | 0 to 9999 sec |
| Derivative time | 0 to 9999 sec |
| Control period | 0.5 to 120.0 sec |
| Manual reset | 0.0 to 100.0% |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation type | Double insulation or reinforced insulation(mark: @(INS), dielectric strength between the measuring input part and the power part: AC power 2kV, AC/DC Power 1kV) |
| Weight | Approx. 204g(approx. 133g) |
Tags: Temp Control, W72 x H72, Single display 4 Digit, PID Control, Relay & SSR Output, 1 Alarm Output, 24VAC 50/60Hz, 24-48VDC
