| Output power | 182.4W |
|---|---|
| Input Voltage | 100-240VAC~ 50/60Hz |
| Permissible voltage | 85-264VAC~ 50/60Hz, 120-370VDC @(=) |
| Output_Voltage | 48VDC @(=) |
| Output_Current | 3.8A |
| Mounting type | DIN Rail |
| Protection | Over-Current/Over-Voltage/Inrush Current/Output Short-Circuit/Remote Control/Output Low-Voltage Indicate/Power Factor Correction/Terminal Cover |
| Approval | @(CE) @(CULUS_LISTED) |
| Input_Frequency | 50/60Hz |
| Input_Efficiency_100VAC~ | 0.89 |
| Input_Efficiency_240VAC~ | 0.92 |
| Input_Power factor | Min. 0.9 |
| Input_Current consumption_100VAC~ | 2.04A |
| Input_Current consumption_240VAC~ | 0.84A |
| Output type_Voltage adjustment range | Max. ?5% |
| Output type_Input fluctuation ratio | Max. ?0.5% |
| Output type_Load fluctuation ratio | Max. ?1% |
| Output type_Ripple&Ripple noise | Max. ?1% |
| Protection structure | IP20(IEC standard) |
| Approval | @(CE) @(UL_LISTED) |
| Environment_Ambient temperature | -10 to 50?? storage: -25 to 65??(surrounding air temp.: Max. 40?? |
| Environment_Ambient humidity | 25 to 85%RH, storage: 25 to 90%RH |
| Weight | Approx. 609g(approx. 505g) |
Tags: Power Supply, Din Rail mounting, Switching, 48 VDC output, 180 Watts, 3.75 Amp 100-240 VAC Input
