| Mechanical characteristics_Operation angle | Left 45?, Right 45? |
|---|---|
| Protection structure | IP52 |
| Approval | @(KC) @(CE) @(CULUS)(LED blocks are except @(KC) certifications) |
| Weight_Mounting hole_?30 | Approx. 21g |
| Weight_Housing | Approx. 7g |
| Operation type | Short lever 3-position, spring return two-way |
| Color | White |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Tags: Selector switch, Diameter 30mm, Flush, Shark-head lever, Non-Illuminated, 3-position, Spring return two-way, Left 45?, Right 45?, White, Head, Requires Contact Block SA-CA, SA-CB, SA-CAM or SA-CBM
