| Mechanical characteristics_Operation angle | Center 0?, Right 90? |
|---|---|
| Protection structure | IP52 |
| Approval | @(KC) @(CE) @(CULUS)(LED blocks are except @(KC) certifications) |
| Weight_Mounting hole_?30 | Approx. 21g |
| Weight_Housing | Approx. 7g |
| Operation type | Short lever 2-position, maintained |
| Color | White |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Tags: Selector switch, ?30mm, Flush, Non-Illuminated, Shark short lever, White, 2-position mantained, Head
