| Wire type and power | DC 3-wire type 12-24VDC @(=) |
|---|---|
| Sensing side diameter | M30 |
| Sensing distance | 15mm |
| Installation | Non-shield(non-flush) |
| Standard sensing target | 45?45?1mm(iron) |
| Response frequency | 200Hz |
| Current specification | Current consumption: Max. 10mA |
| Control output | NPN Normally Closed |
| Material | Brass(nickel plated) |
| Cable Standard/material | Standard connector |
| Protection structure | IP67 |
| Approval | @(CE) |
| Body length | Standard type |
| Environment_Ambient temperature | -25 to 70?? storage: -30 to 80??/td> |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Residual voltage | Max. 1.5V |
| Weight | Approx. 146g(approx. 134g) |
Tags: Sensor, Inductive Prox, 15mm Sensing, M30 Round, Non-Shielded, NPN NC, 3 Wire connector, 10-30 VDC
