| Shaft outer diameter | ?2mm |
|---|---|
| Max. response frequency | 25kHz |
| Max. allowable revolution | 6000rpm |
| Starting torque | Max. 10gf.cm(max. 0.00098N.m) |
| Resolution | 300P/R |
| Output phase | A |
| Control output | NPN open collector |
| Power supply | 5VDC @(=) ?5%(ripple P-P: max. 5%) |
| Connection type | Axial cable type |
| Protection structure | IP50 |
| Approval | @(CE) @(CULUS) |
| Environment_Ambient temperature | -10 to 70?? storage: -20 to 80??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | ?2mm coupling |
| Weight | Approx. 35.4g(approx. 12g) |
Tags: Encoder, Incremental, ?18mm, 2mm Shaft, 400 PPR, A, NPN open collector output, 5VDC, Axial cable type
