Data sheet?

Wire type and power	DC 2-wire type 12-24VDC (10-30VDC )
Sensing side diameter	18mm
Sensing distance	7mm
Installation	Shield(flush)
Standard sensing target	30?30?1mm(iron)
Response frequency	80Hz
Current specification	Leakage current: Max. 0.8mA
Control output	DC 2-wire Normally open
Material	Case/Nut: stainless steel 303 (SUS 303), washer: stainless steel 304 (SUS 304), sensing side: stainless steel 303 (SUS 303, thickness of PRFDWT12/18: 0.4mm, PRFDWT30: 0.5mm), oil resistant cable (gray): oil resistant polyvinyl chloride (PVC)
Cable Standard/material	Oil resistant cable(IEC standard)
Protection structure	IP67(IEC standard)
Approval
Body length	Standard type
Environment_Ambient temperature	-25 to 70?? storage: -25 to 70??/td>
Environment_Ambient humidity	35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)	Max. 15% of sensing distance
Residual voltage	Max. 3.5V
Weight	Approx. 132g(approx. 97g)

??hen using the nut which is not stainless steel 303 (SUS303) material such as brass, the sensing distance is variable.
??he response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
