Data sheet?

Wire type and power	DC 2-wire type 12-24VDC (10-30VDC )
Sensing side diameter	30mm
Sensing distance	12mm
Installation	Shield(flush)
Standard sensing target	54?54?1mm(iron)
Response frequency	50Hz
Current specification	Leakage current: Max. 0.8mA
Control output	DC 2-wire Normally open
Material	Case/Nut: stainless steel 303(SUS 303), washer: stainless steel 304(SUS 304), sensing side: stainless steel 303 (SUS 303, thickness of PRFDT12/18: 0.4mm, PRFDT30: 0.5mm), oil resistant cable (gray): oil resistant polyvinyl chloride (PVC)
Cable Standard/material	Oil resistant cable
Protection structure	IP67(IEC standard)
Approval
Body length	Standard type
Environment_Ambient temperature	-25 to 70?? storage: -25 to 70??/td>
Environment_Ambient humidity	35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)	Max. 15% of sensing distance
Residual voltage	Max. 3.5V
Weight	Approx. 225g(approx. 170g)

??hen using the nut which is not stainless steel 303 (SUS303) material such as brass, the sensing distance is variable.
??he response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
??o not pull the cable with a tensile strength of 50N or over. It may result in fire due to the broken wire. When extending wire, use AWG22 cable or over within 200m.
??able: Option is 5m.
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
