Data sheet?

Display method	4-digit 11-segment LCD
Control method	ON/OFF control, P, PI, PD, PID control
Input specification	Thermocouple: K(CA), J(IC), T(CC), R(PR), S(PR), L(IC) RTD: DPt100?, Cu50?
Sampling cycle	50ms
Control output	Relay (250VAC~ 3A, 30VDC 3A)
Option output	Alarm 1
Power supply	100-240VAC~ 50/60Hz
Protection structure	IP50(front panel)
Approval
Display accuracy_RTD	??t room temperature(23?????:(PV ?0.3% or ?1?? select the higher one) ?1-digit ??ut of room temperature:(PV ?0.5% or ?2?? select the higher one) ?1-digit
Display accuracy_Thermocouple	??t room temperature(23?????:(PV ?0.3% or ?1?? select the higher one) ?1-digit ??ut of room temperature:(PV ?0.5% or ?2?? select the higher one) ?1-digit
Hysteresis(adjustable sensitivity)	1 to 100????0.1 to 50.0???? variable
Proportional band	0.1 to 999.9????/td>
Integral time	0 to 9999 sec
Derivative time	0 to 9999 sec
Control period	0.5 to 120.0 sec
Manual reset	0.0 to 100.0%
Environment_Ambient temperature	-10 to 50?? storage: -20 to 60??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Insulation type	Double insulation (mark: , dielectric strength between primary circuit and secondary circuit: 3kV)
Weight	Approx. 214g(approx. 133g)

??hen using the unit at low temperature (below 0??, display cycle is slow. Control output operates normally.
??? At room temperature(23?????
TC R(PR), S(PR) , below 200?? (PV ?0.5% or ?3?? select the higher one) ?1-digit, over 200?? (PV ?0.5% or ?2?? select the higher one) ?1-digit
TC L(IC), RTD Cu50?: (PV ?0.5% or ?2?? select the higher one) ?1-digit
??Out of room temperature range
TC R(PR), S(PR): (PV ?1.0% or ?5?? select the higher one) ?1-digit
TC L(IC), RTD Cu50?: (PV ?0.5% or ?3?? select the higher one) ?1-digit
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
