Data sheet?

Max. response frequency	180kHz
Max. allowable revolution	5000rpm
Output phase	A, B
Wheel diameter	250mm
Gear ratio	1:1
Number of pulses	250
Min. measurement unit	1mm
Control output	Totem pole
Power supply	12-24VDC ?5%(ripple P-P: max. 5%)
Connection type	Axial cable connector type
Protection structure	IP50
Approval
Environment_Ambient temperature	-10 to 70?? storage: -25 to 85??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 90% RH
Weight	Approx. 494g

??ake sure that max. response revolution should be lower than or equal to max. allowable revolution when selecting the resolution.
[Max. response revolution (rpm) = Max. response frequency/Resolution ? 60sec]
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
