Data sheet?
| Network | DeviceNet |
|---|---|
| Type | Digital |
| Number Of I/Os_Output | 8-point (NPN) |
| I/O specification | Voltage: 10-28VDC (voltage drop: max. 0.5V) Current: 0.3A/point (leakage current: max. 0.5mA) |
| Module type | Basic unit |
| Power supply | 24VDC  |
| Protection structure | IP20 |
| Approval |   |
| Material | Front case, Body Case: PC |
| Insulation type | I/O and inner circuit: insulated, DeviceNet and inner circuit: non-insulated, Power and DeviceNet: non-insulated |
| Environment_Ambient temperature | -10 to 50?? storage: -25 to 75??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 65g |
??xpansion units (ARX-D?????4S) of ARD-D Series (digital, sensor connector type) are available to order separately.
??nvironment resistance is rated at no freezing or condensation.
??his weight is with packaging and the weight in parentheses is only unit weight.
| Field Networks | |
| Type | Standard terminal block |
| Basic/Expansion Unit | Basic unit |
| Digital/Analog | Digital type |
| I/O type | Output type |
| I/O Points | 8 |
| I/O specification | NPN |
| Dimensions | W105 x H52 X L38.5 mm |
| Power Supply | 12 - 24 VDC |
