Data sheet?

Sensing type	Convergent reflective type
Sensing distance	10 to 50mm
Sensing target	Opaque, Translucent material
Light source	Infrared LED
Response time	Operation: Max. 3ms, Return: Max. 100ms
Power supply	12-24VDC ?10%(ripple P-P: max. 10%)
Current consumption	Max. 35mA
Sensitivity adjustment	Fixed
Operation mode	Light ON
Control output	NPN open collector
Timer function	Timer Function
Connection type	Cable type(?3.5, 2m)
Environment_Ambient illumination	Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature	-20 to 65?? storage: -25 to 70??/td>
Protection structure	IP50
Approval
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Hysteresis(distance)	Max. 10% at sensing distance
Material	Case: Acrylonitrile butadiene styrene, Sensing part: Acrylic, Bracket: Steel Plate Cold Commercial, Bolt: Steel Chromium molybdenum, Nut: Steel Chromium molybdenum, Sleeve: Brass, Ni-plate
Accessories	Adjuster driver, Fixing bracket A, M3 Screws, Nuts
Weight	Approx. 75g(approx. 38g)

??FF delay timer is built-in. (delay time: max. 0.1 to 2sec)
??ensing distance: Non-glossy white paper 50?50mm.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
??old separately: Slit (BYD3M-ST: ?1, ?1.5, ?2, ?2.5)
