Data sheet?
| Sensing type | Diffuse reflective type |
|---|---|
| Sensing distance | 5 to 30mm |
| Sensing target | Opaque, Translucent material(min. sensing target: ?0.2mm) |
| Light source | Red LED(650nm) |
| Response time | Max. 1ms |
| Power supply | 12-24VDC  ?10%(ripple P-P: max. 10%) |
| Current consumption | Max. 20mA |
| Operation mode | Light ON |
| Control output | PNP open collector |
| Connection type | Cable type(?2.5, 2m) |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 55?? storage: -40 to 70??/td> |
| Protection structure | IP67 |
| Approval |  |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) | Max. 20% at rated sensing distance |
| Material | Case: polybutylene terephthalate, sensing part: polymethyl methacrylate, bracket: SUS304(steel use stainless 304), bolt: carbon steel, sleeve: SUS304(steel use stainless 304) |
| Accessories | Fixing bracket, M2 bolt: 2 |
| Weight | Approx. 40g (approx. 25g) |
??on-glossy white paper 50?50mm.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
??in. sensing target: Based on 10mm sensing distance.
| Photoelectric Sensor | |
| Sensing type | Diffuse reflective type |
| Sensing distance | 5 - 30 mm |
| Response speed | Opaque, Translucent material(min. sensing target: Ø0.2mm) |
| Light Source | Red LED (650 nm) |
| Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
| Operation mode | Dark ON |
| Control output | NPN open collector |
| Connection | Cable type(Ø2.5, 2m) |
