| Mechanical characteristics_Operation angle | Left 45?, Right 45? |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| Protection structure | IP52 |
| Approval | @(KC) @(CE) @(CULUS)(LED blocks are except @(KC) certifications) |
| Weight_Mounting hole_?30 | Approx. 23.5g |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Singular type A/B contact | Approx. 11g |
| Operation type | Long lever 3-position, spring return two-way |
| Color | White |
| Contact block | A contact: 2 |
| Contact block type | Singular type |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Tags: Seletor Switches ?30, 3 Positions, Auto Spring Return, Left 45 Right 45, Lever, White, 2 Normal Open, 110VAC/10A, 220VAC/5A
