Data sheet?

Mechanical characteristics_Operation angle	Center 0?, Right 90?
Contact block_Electrical specification_Power voltage/current	110VAC~/10A, 250VAC~/6A
LED block_Power supply	110-220VAC~ 50/60Hz
LED block_Current consumption	Max. 20mA
Protection structure	IP52
Approval	(LED blocks are except certifications)
Weight_Mounting hole_?30	Approx. 21g
Weight_Housing	Approx. 7g
Weight_Contact block_Singular type A/B contact	Approx. 11g
Weight_LED block_AC voltage type	Approx. 12g
Operation type	Short lever 2-position, maintained
Color	Red
Contact block	A contact: 1
Contact block type	Singular type
Environment_Ambient temperature	-15 to 55?? storage: -25 to 65??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH

??nvironment resistance is rated no freezing or condensation.
??he LED color is the same as the control unit.
??onnect up to 2 contact blocks. Connect the contact blocks only on the right and left side slots. It will not operate if connected to the center slot.
