Data sheet?

Applicable fluid	(Pneumatic type) Air, Non-corrosive gas
Pressure port direction	Rear fitting
Pressure port	NPT1/8
Connection type	Connector type(connector type cable: 2m)
Pressure type	Standard pressure
Rated pressure range	0 .0 to 100.0kPa
Display pressure unit	MPa, kPa, kgf/cm?, bar, psi
Control output_NPN open collector	NPN open collector
Option input/output	Current output(DC4-20mA)
Power supply	12-24VDC???10%(ripple P-P: max. 10%)
Current consumption	Voltage output type: Max. 50mA Current output type: Max. 75mA
Protection structur	IP40
Control output_Hysteresis	Min. display interval
Control output_Repeat error	?0.2% F.S. ?Min. display interval
Control output_Response time	Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms
Environment_Ambient temperature	-10 to 50?? storage: -20 to 60??/td>
Environment_Ambient humidity	30 to 80% RH, storage: 30 to 80% RH
Material	Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass
Weight	Approx. 165g(approx. 80g)

??span style="font-family: "Titillium Web", Arial, "Open Sans", Helvetica, sans-serif; font-size: 12px;">In hysteresis output mode, detection difference is variable.

??t is allowed to select one analog output type only.
??he weight includes packaging. The weight in parenthesis is for unit only.
??he unit is sealed structure. It is based on atmospheric pressure 101.3kPa.
??.S: Rated pressure.
??here may be ?1-digit error in hysteresis by pressure unit calculation error.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
