Data sheet?

Applicable fluid	(Pneumatic type) Air, Non-corrosive gas
Pressure port direction	Rear fitting
Pressure port	NPT1/8
Connection type	Connector type(connector type cable: 2m)
Pressure type	Negative pressure
Rated pressure range	0.0 to -101.3kPa
Display pressure unit	kPa, kgf/cm?, bar, psi, mmHg, inHg, mmH??
Control output_PNP open collector	PNP open collector
Option input/output	Hold/Auto shift input
Power supply	12-24VDC ?10%(ripple P-P: max. 10%)
Current consumption	Voltage output type: Max. 50mA Current output type: Max. 75mA
Protection structure	IP40
Approval
Control output_Hysteresis	Min. display interval
Control output_Repeat error	?0.2% F.S. ?Min. display interval
Control output_Response time	Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms
Environment_Ambient temperature	-10 to 50?? storage: -20 to 60??/td>
Environment_Ambient humidity	30 to 80% RH, storage: 30 to 80% RH
Material	Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass
Weight	Approx. 165g(approx. 80g)

??n hysteresis output mode, detection difference is variable.
??t is allowed to select one analog output type only.
??he weight includes packaging. The weight in parenthesis is for unit only.
??.S: Rated pressure.
??here may be ?1-digit error in hysteresis by pressure unit calculation error.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
