| Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
| Pressure port direction | Rear fitting(3-direction) |
| Pressure port | NPT1/8 |
| Connection type | Cable type(cable type cable: 2m) |
| Pressure type | Negative pressure |
| Rated pressure range | 0.0 to -101.3kPa |
| Display pressure unit | kPa, kgf/cm?, bar, psi, mmHg, inHg, mmH?? |
| Control output_PNP open collector | PNP open collector |
| Option input/output | Voltage(1-5VDC @(=)) output |
| Power supply | 12-24VDC @(=) ?10%(ripple P-P: max. 10%) |
| Current consumption | Max. 50mA |
| Protection structure | IP40 |
| Approval | @(CE) |
| Control output_Hysteresis | 1-digit fixed(2-digit for psi unit) |
| Control output_Repeat error | ?0.2% F.S. ?1-digit |
| Control output_Response time | Selectable 2.5ms, 5ms, 100ms, 500ms |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Front, Rear case: Polycarbonate(insert glass), Pressure port: die-cast(Zn) |
| Weight | Approx. 200g(approx. 120g) |
