Data sheet?

Applicable fluid	(Pneumatic type) Air, Non-corrosive gas
Pressure port	R1/8
Connection type	Cable type(cable type cable: 3m)
Pressure type	Compound pressure
Rated pressure range	-101.3 to 100.0kPa
Option output	Current output(DC4-20mA)
Power supply	12-24VDC ?10%(ripple P-P: max. 10%)
Protection structure	IP40
Approval
Material	Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass
Environment_Ambient temperature	0 to 50?? storage: -10 to 60??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Sold separately	Sensor connector wire mount plug(CNE-P04-YG)
Weight	Approx. 60g(approx. 26g)

??or more information about sensor connector wire mount plug, refer to '(G) Connector/Socket'.
??he weight includes packaging. The weight in parenthesis is for unit only.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
??.S: Rated pressure.
