Data sheet?
| Wire type and power | AC 2-wire type 100-240VAC~ |
|---|---|
| Sensing side size | Frame size 25mm |
| Sensing distance | 8mm |
| Standard sensing target | 25?25?1mm(iron) |
| Response frequency | 20Hz |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Open |
| Sensing type | Upper sensing type |
| Material | Poly Phenylene Sulfide |
| Protection structure | IP67 |
| Approval |  |
| Environment_Ambient temperature | -25 to 70?? storage: -30 to 80??/td> |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Residual voltage | Max. 10V |
| Weight | Approx. 70g |
??he response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
??he weight includes packaging. The weight in parenthesis is for unit only.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
| Proximity Sensor | |
| Type | Flat (PFI Series) |
| Sensing Distance | 8 mm |
| Header demension / square | 25 mm square |
| Voltage | 100 - 240 VAC |
| Wire Type | AC 2-wire |
| Output Type | Normal Open |
| Frequency | 20 Hz |
