| Wire type and power | DC 2-wire type 12-24VDC @(=) |
|---|---|
| Sensing side diameter | M12 |
| Sensing distance | 4mm |
| Installation | Shield(flush) |
| Standard sensing target | 12?12?1mm(iron) |
| Response frequency | 450Hz |
| Current specification | Leakage current: Max. 0.6mA |
| Control output | Normally Closed |
| Material | Brass(nickel plated) |
| Cable Standard/material | Standard cable |
| Protection structure | IP67 |
| Approval | @(CE) |
| Body length | Standard type |
| Environment_Ambient temperature | -25 to 70?? storage: -30 to 80??/td> |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Residual voltage | Max. 3.5V |
| Weight | Approx. 44g |
| Proximity Sensor | |
| Type | Long distance (PRD Series) |
| Sensing Distance | 4 mm |
| Header demension / square | 12 mm |
| Shield | Shield |
| Connection Type | Cable Outgoing |
| Voltage | 12 - 24 VDC |
| Wire Type | DC 2-wire |
| Appearance | Standard |
| Output Type | Normal Close |
| Frequency | 450 Hz |
