Data sheet?

Wire type and power	DC 2-wire type 12-24VDC
Sensing side diameter	18mm
Sensing distance	5mm
Installation	Shield(flush)
Standard sensing target	30?30?1mm(iron)
Response frequency	80Hz
Current specification	Leakage current: Max. 0.8mA
Control output	Normally Open
Material	SUS303
Cable Standard/material	Oil resistant cable
Protection structure	IP67
Approval
Body length	Standard type
Environment_Ambient temperature	-25 to 70?? storage: -30 to 80??/td>
Environment_Ambient humidity	35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)	Max. 15% of sensing distance
Residual voltage	Max. 3.5V
Weight	Approx. 132g(approx. 97g)

??hen using the nut which is not SUS303 material such as brass, the sensing distance is variable.
??he response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
??ption is 5m.
??he weight includes packaging. The weight in parenthesis is for unit only.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation.
