Data sheet?
| Operation distance_OFF??N | ??5 mm |
|---|---|
| Operation distance_ON??FF | ??15 mm |
| Approval |     |
| Weight | Approx. 199.5g(approx. 214.8g) |
| Power supply | 24VDC ?10% |
| Operating frequency | 100Hz |
| Power consumption | ??400mA |
| Sub output | PNP open collector output - 24 VDC, 10 mA |
| Operation indicator | ON: green, OFF: red |
| Life expectancy | ??20,000,000 times (with low load) |
| Insulation resistance | ??50 M? (500 VDC megger) |
| Protection circuit | Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit |
| Dielectric strength | 1,500 VAC~ 50/60Hz for 1 minute |
| Vibration | 1.0 mm amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 2 hours |
| Vibration_Malfunction | 1.0 mm amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 10 min |
| Shock | 300m/s? (approx. 30G) in each X, Y, Z direction for 3 times |
| Shock_Malfunction | 300m/s? (approx. 30G) in each X, Y, Z direction in output ON/OFF status for 3 times |
| Ambient temperature | -10 to 55?? storage: -20 to 60??/td> |
| Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67(IEC standard) |
| Connection | Cable type |
| Connector type | M12 Connector |
| Material | Body/CAP: PC |
Tags: Safety Non-contact Door Switch, Magnetic, 5M Cable type, 24VDC, IP67
