Data sheet?

Converting Signal	RS232C ??RS485
Available communication distance	RS485: Max. 1.2km
Insulation type	Isolation
Connection method	RS232C: D-sub 9-pin RS485: 4-wire screw terminal (2-wire communication method)
Power supply	12-24VDC
Approval
Communication speed	1,200 to 115,200bps (recommended: 9,600bps)
Communication type	Half duplex type
Multi-drop	Max. 31 multi-drop
Environment_Ambient temperature	-10 to 55?? storage: -20 to 60??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Weight	Approx. 46g

??rotocol and communication speed are set by Hyper terminal. DAQMaster, ParaSet, Modbus Poll. When communicating with Autonics products, set communication speed to 9,600bps.
??here might be some differences in the specification above depending on PC environment.
??nvironment resistance is rated at no freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
