Data sheet?
| Power supply | 12-24VDC  |
|---|---|
| Power consumption | Max. 3W |
| Sound pressure | Max. 105dB(0.1m), max. 95dB(1m) |
| Sound type | 4 types(ambulance, police, ringtone, for elise) |
| Mounting hole | ?66mm |
| Operation indicator | Red LED |
| Protection structure | IP65(front panel) |
| Material_Body | Polycarbonate |
| Material_Cap | Polycarbonate |
| Approval |  |
| Environment_Ambient temperature | -10 to 55?? storage: -20 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 170g(approx. 130g) |
??nput type: N (NPN open collector input)
??ou may sample the melodies at www.autonics.com.
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated no freezing or condensation.
