| Driver_Operation Method | Bipolar constant current Drive |
|---|---|
| Driver_Applied Motor | Frame size 56mm, shaft type, built-in brake type 2-phase closed-loop stepper motor(Ai-M-56MA-B) |
| Driver_Resolution | 500, 1000, 1600, 2000, 3200, 3600, 5000, 6400, 7200, 10000(SW2) |
| Driver_Power supply | 24VDC @(=) |
| Driver_Max. Run Current | 3.5A/Phase |
| Driver_Max. Power consumption | 120W |
| Driver_Output | In-Position, Alarm Out, Brake, Encoder signal(A, @(A^), B, @(B^), Z, @(Z^)) |
| Driver_Protection structure | IP20 |
| Driver_Approval | @(CE) |
| Driver_Environment_Ambient temperature | 0 to 50?? storage: -20 to 70??/td> |
| Driver_Environment_Ambient humidity | 35 to 85%RH, storage: 10 to 90%RH |
| Driver_Weight | Approx. 400g(approx. 290g) |
Tags: 2-Phase Closed-Loop Stepper Motor Driver, 3.5A/Phase, Built-in brake, 24VDC, ( Req. Ai-M-56MA-B Motor )
