Data sheet?

Driver_Operation Method	Bipolar constant current Drive
Driver_Applied Motor	Frame size 60mm 2-phase closed loop stepper motor
Driver_Resolution	500, 1000, 1600, 2000, 3200, 3600, 5000, 6400, 7200, 10000 PPR
Driver_Power supply	24VDC
Driver_Max. Run Current	3.5A/Phase
Driver_Max. Power consumption	240W
Driver_Output	In-Position, Alarm, Warning, Compare1 / 2, general output(OUT0~9)
Driver_Protection structure	IP20
Driver_Approval
Motor phase	2-Phase
Driver_Environment_Ambient temperature	0 to 50?? storage: -10 to 60??/td>
Driver_Environment_Ambient humidity	35 to 85%RH, storage: 10 to 90%RH
Driver_Weight	Approx. 460g(approx. 300g)
Motor_Number Of Axes	1-axis

??ax. power consumption during operation. When changing the load rapidly, instantaneous peak current may increase. The capacity of power supply should be over 1.5 to 2 times of max. power consumption.
??UN current varies depending on the input RUN frequency and max. RUN current at the moment varies also.
??esolution, Speed filter: Settable with the dedicated program.
??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
