| Rated voltage | 24VDC @(=) ?10% |
|---|---|
| Rated load voltage & current | 75-240VAC~ 50/60Hz 2A |
| Current consumption | ??18mA |
| Applied SSR | AQG22124(Panasonic) |
| Terminal type | Screwless |
| Terminal pitch | 9.0mm(arranging over 2 units) |
| Indicator | Blue LED |
| Applicable cable_Solid wire | ?0.6 to ?1.25mm(60??only) |
| Applicable cable_Stranded wire | AWG22-16(0.30 to 1.25mm?)(60??only) |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 2,500VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 1,000VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Terminal block: Polyamide 66, Conducting plate: Brass, CASE&BASE: Poly phenylene sulfide |
| Accessories | Jumper bar: 1 |
| Protection structure | IP20(IEC standard) |
| Approval | @(CE) @(CULUS_LISTED) |
| Weight | Approx. 140g(approx. 22g) |
Tags: SSR Terminal Block, Screwless type, 1 SSR, Panasonic AQG22124 SSR, NPN Input, 24VDC
