| Rated voltage | ??50VDC @(=), 250VAC~, 50/60Hz |
| Rated current | Max. 10A |
| Common type | Left +COM, Right -COM |
| Terminal type | Screwless |
| Number of terminal | 50 EA |
| Terminal pitch | 5.0mm |
| Applicable cable_Solid wire | ?0.6 to ?1.25mm(60??only) |
| Applicable cable_Stranded wire | AWG22-16(0.30 to 1.25mm?)(60??only) |
| Stripped wire length | 8 to 10mm |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength | 3,000VAC~ 50/60Hz for 1 minute (between open terminals) |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Terminal: polyamide 66, conductive plate: copper, tin plated, case: polycarbonate, base: polycarbonate |
| Approval | @(CE) @(CULUS_LISTED) |
| Weight | Approx. 164g(approx. 97g) |
