| Rated voltage | 24VDC @(=) ?10% |
| Rated load voltage & current | 250VAC~ 5A, 30VDC @(=) 5A |
| Current consumption | ??0mA |
| Applied relay | G6B-1174P-FD-US[OMRON] |
| Number of relay points | 1-point |
| Indicator | Operation indicator: Blue LED |
| Applicable cable | AWG19??4(0.65 to 2.0mm?) |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 3,000VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 1,000VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE & BASE: PA6, TERMINAL PIN: Brass |
| Approval | @(CE) @(UL_LISTED) |
| Weight | Approx. 416g(approx. 30g) |
