| Rated voltage | ??25VDC @(=), 125VAC~ 50/60Hz |
| Rated current | Max. 10A |
| Common type | Left +COM, Right -COM |
| Number of terminal | 20 EA |
| Terminal pitch | 7.0mm |
| Applicable cable | AWG22-16(0.30 to 1.25mm?) |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength | 600VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE: MPPO, TERMINAL PIN: Brass |
| Approval | @(CE) @(UL_LISTED) |
| Weight | Approx. 92g(approx. 61g) |
