| Rated voltage | 24VDC @(=) ?10% |
| Rated load voltage & current | 250VAC~ 2A, 30VDC @(=) 2A(2A/1?? 8A/1 COM) |
| Current consumption | ??.5mA/??3.5mA |
| Applied relay | PA1a-24V [MATSUSHITA(Panasonic)] |
| Number of relay points | 32-point(8-point/1 COM) |
| Number of connector pins | 40-pin |
| Indicator | Power indicator: Red LED, operation and disconnection indicator: Blue LED |
| Applicable cable | AWG22-16(0.30 to 1.25mm?) |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 2,000VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 1,000VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE: MPPO, BASE: Polyamide 66 (G25%), TERMINAL PIN: Brass |
| Approval | @(CE) @(UL_LISTED) |
| Weight | Approx. 438g(approx. 345g) |
