| Rated voltage | 24VDC @(=) ?10% |
| Rated load voltage & current | 250VAC~ 3A, 30VDC @(=) 3A |
| Current consumption | ??8mA |
| Applied relay | APAN3124 [MATSUSHITA(Panasonic)] |
| Number of relay points | 4-point |
| Indicator | Operation indicator: Blue LED |
| Applicable cable | AWG22-16(0.30 to 1.25mm?) |
| Insulation resistance | ??,000M??(at 500VDC megger) |
| Dielectric strength_Between coil-contacts | 3,000VAC 50/60Hz for 1 minute |
| Dielectric strength_Between same contacts | 1,000VAC 50/60Hz for 1 minute |
| Environment_Ambient temperature | -15 to 55?? storage: -25 to 65??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE & BASE: Modified Polyphenylene Oxide, TERMINAL PIN: Brass |
| Accessories | Jumper bar: 2(Model:JB-7.62-04) |
| Approval | @(CE) @(CULUS_LISTED) |
| Weight | Approx. 104g(approx. 68g) |
