Data sheet?

Mechanical characteristics_Operation angle	Center 0? , Right 90?
Contact block_Electrical specification_Power voltage/current	110VAC~/10A, 250VAC~/6A
LED block_Power supply	12-24VAC~ 50/60Hz, 12-24VDC
LED block_Current consumption	Max. 20mA
Protection structure	IP52
Approval	(LED blocks are except certifications)
Weight_Mounting hole_?22/25	Approx. 16g
Weight_Housing	Approx. 7g
Weight_Contact block_Modular type A/B contact	Approx. 10g
Weight_LED block_AC/DC voltage type	Approx. 11g
Operation type	Short lever 2-position, maintained
Color	Blue
Contact block	A contact: 1, B contact: 1
Contact block type	Modular type
Environment_Ambient temperature	-15 to 55?? storage: -25 to 65??/td>
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH

??nvironment resistance is rated no freezing or condensation.
??he control unit, contact blocks, LED blocks are sold separately.
??he LED color is the same as the control unit.
??onnect up to 2 contact blocks. Connect the contact blocks only on the right and left side slots. It will not operate if connected to the center slot.
