Data sheet?

Power supply	15-35VDC
Output	DC4-20mA 2-wire Low-limit: 3.6mA(-2.5%), high-limit: 21.6mA(+10%)
Accuracy	?0.2% of F.S.
Environment_Ambient temperature	-20 to 70?? storage: -20 to 80??/td>
Environment_Ambient humidity	0 to 85%RH
Material	Body: aluminum (AlDc.8S), cover O-Ring: buna N, diaphragm: stainless steel 316, connections: stainless steel 316
Explosion class	Ex d IIC T6
Approval
Measurement pressure	Absolute pressure
Protection structure	IP67(IEC standard)
Pressure range	0 to 0.1MPa
Mounting bracket	Without bracket
Weight	Approx. 1.2kg
Pressure port	G3/8(PF)

??rite the desired pressure range and it is the default of user pressure range. (select "Z" at pressure range)
??pan: User pressure range [ ], URL: Pressure range by model
??he weight includes packaging. The weight in parenthesis is for unit only.
??he temperature or humidity mentioned in Environment indicates a non freezing or condensation environment.
??his Explosion class is acquired and managed by Konics Co., Ltd.
