| Basic Step Angle [FULL/HALF] | 0.72?/0.36? |
|---|---|
| Max. holding torque | 21kgf.cm |
| Rotor Moment Of Inertia | 1400g?cm? |
| Winding Resistance | 0.4? |
| Rated current | 2.8A/Phase |
| Motor length | 103mm |
| Shaft type | Single shaft |
| Wire connection | Pentagon |
| Protection structure | IP30 |
| Approval | @(CE) |
| ElectroMagnetic brake_Rated excitation voltage | 24VDC @(=)?10%(no-polarity) |
| ElectroMagnetic brake_Rated excitation current | 0.62A |
| ElectroMagnetic brake_Static friction torque | 40kgf.cm |
| ElectroMagnetic brake_Rotation part inertia moment | 153?10@(^-7)kgf.cm? |
| ElectroMagnetic brake_B type brake | Power on: brake is released, power off: brake is operating |
| ElectroMagnetic brake_Operating time | Max. 60ms |
| ElectroMagnetic brake_Releasing time | Max. 15ms |
| Weight | Approx. 2.74kg(approx. 2.64kg) |
| Stepper Motor Driver | |
| Basic Step Angle | 0.72º/0.36º |
| Max. holding torque | 21kgf.cm |
| Rotor Moment Of Inertia | 1400g·cm² |
| Winding Resistance | 0.4Ω |
| Rated Current | 2.8A/Phase |
| protection struture | IP30 |
