Data sheet?

Control phase	2-Phase
Heatsink	Heatsink
Mounting type	Panel, DIN rail
Rated input voltage	90-240VAC~
Rated load voltage	48-480VAC~
Dielectric strength	4,000VAC~
Rated load current	75A
Function	Zero cross turn-on
Approval
Environment_Ambient temperature	-30 to 80??in case of the rated input voltage 90-240VAC~: -30 to 70??, Storage: -30 to 100?? The rated load current capacity is different depending on ambient temperature. Refer to '??SSR Derating Curve'.)
Environment_Ambient humidity	45 to 85% RH, storage: 45 to 85% RH
Weight	approx. 2354g(approx. 2064g)

??he weight includes packaging. The weight in parenthesis is for unit only.
??nvironment resistance is rated at no freezing or condensation.
??or wiring the terminal, an O-ring terminal must be used.
??ated load current capacity is varied by ambient temperature. Refer to ??SR Derating Curve of Autonics??total catalogue.
