Data sheet?
| Display Specifications_LCD Type | 4.4 inch STN Blue Negative |
|---|---|
| Display Specifications_Resolution | 240?80 pixel |
| Display Specifications_Display Area | 112.8?37.6mm |
| Display Specifications_Color | MONO(Blue, White) |
| Graphic Drawing Memory | 512KB |
| Touch method | Pressure sensitive type |
| Interface_RS232C | 1 EA |
| Power supply | 24VDC  |
| Protection structure | IP65F(front panel) |
| Dedicated Software | GP Editor(drawing program) |
| Graphic drawing Perfomance_Language | English, Korean, Japanese, Chinese, Russian, Vietnamese, Portuguese |
| Graphic drawing Perfomance_Text | ??High resolution display up to 400 letters (6?8 font) ??6?8, 8?8 ASCII characters, high definition numbers ??8?16 ASCII characters, 16?16 character by each country (1-8 times bigger for width, 0.5-5 times bigger for height) |
| Graphic drawing Perfomance_Number of user screen | 500 pages |
| Graphic drawing Perfomance_Touch switch | Width 15?Height 4 = 60 |
| Real-time controller | RTC embedded |
| Accessories | Fixing bracket: 4, Rubber waterproof ring, Battery (included) |
| Environment_Ambient temperature | 0 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 413g (approx. 284g) |
??anguage could be added in the future
??his weight is with packaging and the weight in parentheses is only unit weight.
??nvironment resistance is rated at no freezing or condensation.
| HMI | |
| Monitor Size | 4.4 inch |
| Item | Graphic panel |
| LCD type | STN LCD |
| Serial interface | RS232C (2) |
| Dimensions | 145 x 75 mm |
| Power supply | 12 - 24 VDC |
