Data sheet?
| Display Specifications_LCD Type | TFT Color LCD |
|---|---|
| Display Specifications_Resolution | 800?320 pixel |
| Display Specifications_Display Area | 108?43.2 mm |
| Display Specifications_Color | 16,777,216 colors |
| Graphic Drawing Memory | 64MB |
| Touch method | Pressure sensitive type |
| Interface_RS232C | 1 EA |
| Interface_RS422 | 1 EA |
| Interface_Ethernet | IEEE802.3(U), 10/100Base-T |
| Power supply | 24VDC  |
| Protection structure | IP65(front panel, IEC standard) |
| Dedicated Software | atDesigner |
| Approval |   |
| Interface_USB(Host) | 1 EA |
| Interface_USB(Device) | 1 EA |
| Graphic drawing Perfomance_Language | English, Korean |
| Graphic drawing Perfomance_Text | Bitmap and vector font |
| Graphic drawing Perfomance_Number of user screen | 100 pages |
| Real-time controller | RTC embedded |
| Environment_Ambient temperature | 0 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 382g(approx. 272g) |
Tags: Color LCD Graphic Panel, 4.6 inch, RS232C, RS422, Ethernet, 24VDC
