Data sheet?
| Display method | 4-digit 7-segment LED |
|---|
| Character height | 10mm |
|---|
| Max. display Range | -1999 to 9999 |
|---|
| Measurement | Digital scaling |
|---|
| Input specification | DC4-20mA |
|---|
| Power supply | Loop power |
|---|
| Output_Main Output(Comparative Value) | Indicator |
|---|
| Display accuracy | F.S. 0.3% rdg ?1-digit |
|---|
| Display cycle | 0.5 sec/1 sec/2 sec/3 sec/4 sec/5 sec |
|---|
| Resolution | 12,000 resolution |
|---|
| Environment_Ambient temperature | -10 to 50?? storage: -25 to 60??/td> |
|---|
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
|---|
| Weight | Approx. 44g |
|---|
??mbient temperature (25?????: F.S. 0.3% rdg of ?1-digit (-10 to 50?? F.S. 0.4% rdg ?1-digit)
??mpedance between input lines: Max. 600? (based on 24VDC)
Please be aware that activating input power is based on 24VDC, and the recommended impedance also will be lowered if the activating power is lower.
??nvironment resistance is rated at no freezing or condensation.
??he weight includes packaging. The weight in parenthesis is for unit only.
