| Display method | 3?-digit 7-segment LED |
|---|---|
| Character height | 10mm |
| Max. display Range | 0 to 1999 |
| Measurement | DC current |
| Input specification | 0-199.9mA |
| Power supply | 12-24VDC @(=) |
| Output_Main Output(Comparative Value) | Indicator |
| Display accuracy | F.S. 0.2% rdg ?1-digit |
| Sampling cycle | 300ms |
| Max. allowable input | 150% of measurement input range |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 44g |
Tags: Meter, Amp Meter, LED, W48xH24mm, 3 1/2-Digit, 199.9mA, Full Scale, 12-24 VDC
