| Display method | 12 segment (measurement value display part: white, character height: 19mm), other display parts(red, green, yellow, indicator model: white) LCD method |
|---|---|
| Character height | 19mm |
| Max. display Range | -9999 to 9999(4digit) |
| Measurement | DC voltageAC voltage, Frequency |
| Input specification | DC ?500mV, ?200mV, ?50mV, ?20V, ?5V, 1-5V, ?2V, ?500V, ?200V, ?50V, AC 0-500mV, 0-200mV, 0-50mV, 0-20V, 0-5V, 0-2V, 0-500V, 0-200V, 0-110V, 0-50V |
| AC Measurement | Select RMS value /AVG value measurement methods |
| Power Factor Display | Power factor display are available when input type is DC. |
| Power supply | 24-240VAC~ 50/60Hz, 24-240VDC @(=) |
| Output_Main Output(Comparative Value) | NPN open collector output |
| Approval | @(CE) @(CULUS) |
| Max. allowable input | ??DC input: approx. -110 to 110% of each measurement input range(when not using minus input: -10 to 110%)??AC input: approx. 110% of each measurement input range |
| Display accuracy | 23?5??- DC input: ?0.1% F .S. ?2digit, AC input: ?0.3% F .S. ?3digit ??he teminal for 5A of current input, ?0.3% F .S. ?3digit, 0~50??- AC/DC input: ?0.5% F .S. ?3digit ??he teminal for 5A of current input, ?1% F .S. ?3digit |
| Display cycle | 0.2 to 5.0 sec (select per 0.1 sec) |
| Environment_Ambient temperature | -10 to 50?? storage: -20 to 60??/td> |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 100g(approx. 77g) |
Tags: Meter, AC/DC Volts, LCD, W96xH48mm, 4-Digit, 0-500V Input, 24-240 VAC/VDC, NPN output
