| Sensing type | Through-beam type |
|---|
| Sensing distance | 3m |
|---|
| Sensing target | Opaque material of min. ?6mm |
|---|
| Light source | Infrared LED |
|---|
| Response time | Max. 1ms |
|---|
| Power supply | 12-24VDC  ?10%(ripple P-P: max. 10%) |
|---|
| Current consumption | Emitter/Receiver: Max. 30mA |
|---|
| Sensitivity adjustment | Fixed |
|---|
| Operation mode | Dark ON(option: Light ON) |
|---|
| Control output | NPN open collector |
|---|
| Connection type | Cable type(?3.5, 2m) |
|---|
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
|---|
| Environment_Ambient temperature | -20 to 65?? storage: -25 to 70??/td> |
|---|
| Protection structure | IP64 |
|---|
| Approval |  |
|---|
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
|---|
| Material | Case: Acrylonitrile butadiene styrene, Sensing part: Acrylic, Bracket: Steel Plate Cold Commercial, Bolt: Steel Chromium molybdenum, Nut: Steel Chromium molybdenum, Sleeve: Brass, Ni-plate |
|---|
| Accessories | Fixing bracket A, M3 Screws, Nuts |
|---|
| Weight | Approx. 105g(approx. 80g) |
|---|
