| Wire type and power | DC 3-wire type 12-24VDC @(=) |
| Sensing side size | Frame size 25mm |
| Sensing distance | 8mm |
| Standard sensing target | 25?25?1mm(iron) |
| Response frequency | 200Hz |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Open |
| Sensing type | Upper sensing type |
| Material | Heat-resistant ABS |
| Protection structure | IP67 |
| Approval | @(CE) |
| Different frequency | Differential frequency type |
| Environment_Ambient temperature | -25 to 70?? storage: -30 to 80??/td> |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Weight | Approx. 70g |
