| Wire type and power | AC 2-wire type 100-240VAC~ |
|---|
| Sensing side diameter | M12 |
|---|
| Sensing distance | 2mm |
|---|
| Installation | Shield(flush) |
|---|
| Standard sensing target | 12?12?1mm(iron) |
|---|
| Response frequency | 20Hz |
|---|
| Current specification | Leakage current: Max. 2.5mA |
|---|
| Control output | Normally Open |
|---|
| Material | Brass(nickel plated) |
|---|
| Cable Standard/material | Standard connector |
|---|
| Protection structure | IP67 |
|---|
| Approval |  |
|---|
| Body length | Standard type |
|---|
| Environment_Ambient temperature | -25 to 70?? storage: -30 to 80??/td> |
|---|
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
|---|
| Hysteresis(distance) | Max. 10% of sensing distance |
|---|
| Residual voltage | Max. 10V |
|---|
| Insulation type | Double insulation or reinforced insulation(mark:  , dielectric strength between the measuring input part and the power part: 1kV) |
|---|
| Weight | Approx. 42g(approx. 30g) |
|---|
